Product Features
- Built-in Active Power Factor Correction (PFC) ensures a power factor of above 0.95, effectively reducing energy losses in the power system and equipment loads, surpassing EN 61000-3-2 Class A.
- It includes automatic voltage regulation to prevent fluctuations in power supply voltage from affecting the inverter’s performance.
- Incorporating an ErP module compliant with EU Directive ErP 2009/125/EC, it automatically cuts off power (including control and inverter) during sleep mode, with standby power consumption less than 0.2W.
- It provides a 60W (12VDC, 5A) power supply for control.
- Featuring a built-in motor control module supporting analog DC 0-5V and optical pulse signals for position feedback, it offers continuous lift control for easy automatic calibration.
- A dynamic braking resistor activates automatically to suppress inverter PN voltage when the motor voltage rises too high, preventing damage. An external braking module is optional.
- An external AC fan can be connected, with the inverter controlling its activation based on temperature detection and preset parameters.
- Temperature-controlled fans can be set to start and stop automatically according to temperature levels, enhancing energy efficiency, reducing noise, and facilitating maintenance with a quick-detach design to extend fan’s life.
- Parameter protection with password encryption allows customization of parameter access levels (modifiable, read-only, or hidden), ensuring parameter’s security and management.
- The inverter automatically records operating hours for control reference in treadmill maintenance and management planning.
Safety Function
- The inverter design complies with insulation distance requirements of EN 60335-1 / UL61800-5-1 and safety standards of UL 60730-1 / UL 1647.
- It meets CE certification specifications and can be optionally equipped with EMC filters to effectively suppress electromagnetic interference, meeting the electromagnetic compatibility requirements of various countries.
